Air-cooled diesel engines
FSH173F
FSH173F is a 247 cc, 5.5 HP air-cooled, single-cylinder, four-stroke diesel engine for selected KAMA, KIPOR and 173F-type replacement applications. It is suitable for water pumps, generator sets, power tillers, cultivators and other agricultural equipment. Confirm shaft dimensions, mounting pattern, rotation direction and starting system before ordering.
Key figures
The three numbers buyers ask for first, followed by the full catalogue row for FSH173F.
Specification
Every figure our catalogue prints for FSH173F, under Diesel engine range — air-cooled.
FSH173F — full specification
| Specification | FSH173F |
|---|---|
| Bore × stroke (mm) | 73 × 59 |
| Displacement (L) | 0.247 |
| Rated output (kW) | 5.5 HP / 4.0 kW |
| Fuel tank (L) | 2.5 |
| Lubricating oil (L) | 0.75 |
| Packing size L×W×H (mm) | 415 × 385 × 470 |
| 20FT unit | 312 |
| Net weight (KG) | 28 kg manual start / 32 kg electric start |
| Engine type | Air-cooled, 4-stroke, single-cylinder diesel engine |
| Valve design | Side valve |
| Combustion system | Direct injection |
| Rotation direction | Counterclockwise, facing PTO shaft |
| Fuel | Diesel |
| Lubricating system | Pressure splashed |
| Starting system | Recoil or electric start |
| Reference class | KAMA, KIPOR 173F-class applications |
| Applications | Water pumps, generator sets, power tillers and cultivators |
| Mounting | Confirm shaft and mounting dimensions before ordering |
Typical applications
Where the FSH173F is normally put to work. Each one opens the full write-up: what the job needs, and where this class of machine stops being the right answer.
Irrigation and drainage
Engine-driven pump sets that move water where there is no mains supply — from a 2 inch portable unit to a 6 inch set delivering 160 m³/h.
Read the guideRoad and concrete works
Bidirectional plate compactors on 690 × 480 mm and 900 × 680 mm plates, plus concrete placement and finishing equipment for groundworks.
Read the guideStandby and site power
Gasoline and diesel generating sets from 0.8 kVA to 9.5 kW, for backup power at shops, farms and events, and for tools on construction sites.
Read the guideFarm mechanisation
Walk-behind power tillers from 7 HP to 13 HP for soil preparation on smallholdings, in orchards and on terraced or enclosed ground.
