Plate compactors and site machines
Construction machinery
Compact machines for groundworks, paving and concrete placement, built for daily use on site and matched to the engine range.
Models in this range
2 models in 1 series. Open any model for the figures our catalogue prints for it, and to start a quotation.
At a glance
The points that decide a specification most often — taken from the model data below.
Bidirectional compaction
Forward and reverse travel on the plate compactor range.
50 kN impact force
FSHC-330 delivers 50 kN at 3600 rpm.
Engine matched
Powered by GX, 178F, 186F, 192F and 420 class engines.
Container friendly
55 to 60 units per 20 ft container.
Frequently asked questions
What buyers ask before specifying construction machinery — answered from the catalogue figures on this page.
What impact force do the compactors deliver?
35 kN on the FSHC-160 and 50 kN on the FSHC-330. The FSHC-330 runs at 3600 rpm and the FSHC-160 at 3840 rpm.
Do they travel in reverse as well as forward?
Yes. Both models are bidirectional, with a travelling speed of 20–25 m/min and a limited grade ability of 20.
What plate size does each model use?
690×480 mm on the FSHC-160 and 900×680 mm on the FSHC-330.
How many units fit in a container?
60 units of the FSHC-160 or 55 of the FSHC-330 per 20 ft container.
Which engines are used?
GX390, 178F or 186F class engines on the FSHC-160, and GX420, 186F or 192F on the FSHC-330. Both are recoil start.
Compare all models
Transcribed from our printed catalogue. Scroll the table sideways to see every model.
Bidirectional vibratory plate compactor
| FSHC-160 | FSHC-330 | |
|---|---|---|
| Plate size L*W (mm) | 690*480 | 900*680 |
| Max travelling speed (m/min) | 20-25 | 20-25 |
| Limited grade ability | 20 | 20 |
| Frequency (rpm) | 3840 | 3600 |
| Impact force (kN) | 35 | 50 |
| Engine model | GX390 / 178F / 186F | GX420 / 186F / 192F |
| Starting system | Recoil starter | Recoil starter |
| Packing size (L*W*H) mm | 700*500*900 | 1025*700*1260 |
| Net weight (KG) | 160 | 305 |
| 20 feet container | 60 | 55 |
