Gasoline generating sets
FSH3500
FSH3500 is a brush single/three-phase gasoline generating set with AVR voltage regulation. Rated output 2.5/3.0 kVA, maximum 2.8/3.5 kVA at 50/60 Hz, driven by the FSH210 OHV engine. Net weight 51 kg.
Key figures
The three numbers buyers ask for first, followed by the full catalogue row for FSH3500.
Rated AC output (kVA)2.5/3.0
Engine modelFSH210
Net weight (KG)51
Specification
Every figure our catalogue prints for FSH3500, under Gasoline generator set.
FSH3500 — full specification
| Specification | FSH3500 |
|---|---|
| Type | Brush single/three phase |
| Voltage regulate | AVR |
| Frequency (Hz) | 50/60 |
| Rated AC voltage (V) | 110/120/220/230/240, 220/380 |
| Rated AC output (kVA) | 2.5/3.0 |
| Max AC output (kVA) | 2.8/3.5 |
| Power factor | 1 |
| Engine model | FSH210 |
| Engine type | OHV 4-stroke forced air-cooled |
| Fuel tank capacity (L) | 15 |
| Ignition system | T.C.I |
| Starting system | Recoil / electric start |
| Packing size (L*W*H) mm | 610*535*470 |
| Net weight (KG) | 51 |
| 20/40 FT unit | 225/475 |
